• 3D Imaging Every Day

    The OEC 3D is a true 3D/2D C-arm with the flexibility to acquire both precise 3D and 2D images without switching systems. Transitioning quickly and easily provides greater efficiency and versatility for a wide range of clinical applications from spine and orthopedics to cardiac and vascular. Finally, a 3D C-arm that every surgical suite deserves.

Clinical Images

  • Spinal Vertebral Body Tether – Volume Rendering

  • Spinal Vertebral Body Tether – Maximum Intensity Projection

  • Spinal Vertebral Body Tether – Axial

  • Sacroiliac Tumor Excision – Volume Rendering

  • Sacroiliac Tumor Excision – Axial

  • Sacroiliac Tumor Excision – Sagittal

  • Tibia Fracture – Volume Rendering

  • Tibia Fracture Reduction – Coronal

  • Tibia Fracture Reduction – Maximum Intensity Projection

Precise Images

  • See more levels during a spinal fusion, or more of the pelvis or femur during an orthopedic procedure. With a 19 cm x 19 cm x 19 cm volume, OEC 3D captures a 67% greater volume than other 3D C-arms*.

    *Compared to other 3D C-arm published specifications.

  • Capturing as much data as possible is critical in creating highly detailed images. The OEC 3D delivers a true 200° isocentric orbital sweep, 35° more than other 3D C-arms*, for comprehensive 3D volumetric images.

    *Compared to other 3D C-arm published specifications.

Key features

OEC 3d point of interest
  • See large anatomy with
    19 cm x 19 cm x 19 cm volume
    19cm volume
  • Convenient control from workstation to
    OEC Touch
    OEC 3D Convenient Control
  • Easy positioning with lightest weight 3D C-arm
    OEC_3D_push_ carm
  • Comprehensive 3D imaging with 200° isocentric sweep with 512³ resolution
    Isocentric sweep
  • Preview FOV on patient anatomy without X-ray with Live View
    OEC 3D LIve View
  • OEC Open exports high fidelity 3D data sets to navigation, robotics and AI enabled applications
    Open export
  • Simple Setup Assistant guides users through 3D scan steps
    3d-screen1-hd
  • True 3D/2D imaging to improve clinical flexibility and asset utilization
    true 3D imaging
  • Analyze precise 3D perspectives with Volume Viewer
    Volume Viewer


Fast Facts

  • Position detector without X-ray with Live View stereo vision depth camera

  • Set up 3D imaging with simple step-by-step interactive guide

  • Protect patient data with encryption and Linux operating system
  • Seamless integration with navigation robotics, or AI enabled technology

  • Designed for asset utilization with 3D and 2D imaging

  • Easily position around patient with lightest weight 3D C-arm

  • Extensive connectivity to PACS and additional monitors

  • Optimize dose for clinician and patient with a variety of dose features
